Specifications

Max Recirculating (Scrubbing) CFM: 1680 cfm / 2800 m³h

Max Exhaust CFM: 840 cfm / 1400 m³h@ 0.1 sec contact time
Recommended Min Airflow: 420 cfm / 700 m³h
Prefilter: Yes
Flange: 8", 10", 12"
Dimensions: (with pre-filter)
·Outside Diameter: 42 cm / 16.5"
·Height: 100 cm / 39.4"
·Weight: 47kg / 103lbs.
·Carbon Weight: 37kg / 81.5lbs.
·Carbon Bed Depth: 6.5 cm / 2.56"
Max Operating Temp: 80ºC
Pressure drop at max cfm: 180pa / .75"wg

Recommended Can-Fan:
FAN                         Watts Consumed           Filtered Air CFM

Max-Fan 14"                  240 Watts                       958 CFM
Max-Fan 12"                  488 Watts                     1260 CFM
Can-Fan 12" HO           310 Watts                       825 CFM

Max-Fan 10"                   228 Watts                       834 CFM
Can-Fan 10" HO           267 Watts                       641 CFM

Max-Fan 8"                     165 Watts                       580 CFM

Can-Fan 8" HO              278 Watts                      600 CFM
